Mini Box Expandable Sleeving

Quantity:
  • MiniPET

The Mini Box contains between 3 and 15 metres of PET braided expandable sleeving, wound on a environment-friendly clear plastic reel and neatly packaged in a white/printing dispenser box (170 x 165 x 55mm).It is an ideal storage solution for expandable cable sleeving, providing easy dispensing of shorter lengths.
Normal Size Expansion Range Ends Carriers Package
(Mts /box)
Box size(cm)
mm inch Min.(I) Max.(O) inch
3.2 1/8" 2.4 6.4 3/32"~1/4" 1 32 15 5.5*16.5*17.0
6.4 1/4" 3.2 11.1 1/8"~7/16" 3 24 15 5.5*16.5*17.0
7.9 5/16" 3.8 12.7 5/32"~1/2" 3 32 12 5.5*16.5*17.0
9.5 3/8" 4.7 15.9 3/16"~5/8" 3 36 10 5.5*16.5*17.0
12.7 1/2" 6.4 31.8 1/4"~3/4" 3 48 10 5.5*16.5*17.0
16.0 5/8" 9.5 25.4 3/8"~1" 3 56 8 5.5*16.5*17.0
19.0 3/4" 12.7 31.8 1/2"~1-1/4" 3 64 5 5.5*16.5*17.0
25.4 1" 15.9 41.3 5/8"~1-5/8" 3 72 5 5.5*16.5*17.0
32.0 1-1/4" 19.1 44.5 3/4"~1-3/4" 3 96 4 5.5*16.5*17.0
