Silicone Flex Glass (SRX) sleeving is engineered with a silicone rubber coating over an insulating fiberglass sleeve. SRX is very abrasion resistant and is ideal in heavy duty applications that require outstanding mechanical and electrical properties.
The mechanical properties and high dielectric strength of SRX make it the first choice in applications such as transformer lead protection, motor coil leads, component isolation, and power supply wiring. SRX has a high tear strength, slight expandability for easy installation, excellent flex life and resistance to fatigue. It is Class C rated (235℃) with an operating temperature range of –70℃ to 235℃. SRX shows no discernible effects under exposure of up to 10 megarads of radiation.
Silicone Flex Glass (SRX) sleeving is engineered with a silicone rubber coating over an insulating fiberglass sleeve. SRX is very abrasion resistant and is ideal in heavy duty applications that require outstanding mechanical and electrical properties.
The mechanical properties and high dielectric strength of SRX make it the first choice in applications such as transformer lead protection, motor coil leads, component isolation, and power supply wiring. SRX has a high tear strength, slight expandability for easy installation, excellent flex life and resistance to fatigue. It is Class C rated (235℃) with an operating temperature range of –70℃ to 235℃. SRX shows no discernible effects under exposure of up to 10 megarads of radiation.
Size
Tolerance
Min. Wall Thickness
Cutting Length
Package (Meters/Roll)
(mm)
(mm)
(mm)
(mm)
0.5~1.0
0.2
0.30
50~1000
400
1.5~3.0
0.25
0.35
50~1000
200
3.5~5.0
0.25
0.40
50~1000
200
6.0~8.0
0.25
0.45
50~1000
100
9.0~10.0
0.50
0.50
50~1000
100
11.0~14.0
0.50
0.60
50~1000
50
15.0~20.0
1.00
0.65
50~1000
50
22.0~25.0
1.00
0.85
50~1000
25
26.0~30.0
1.00
0.95
50~1000
25
32.0~40.0
1.00
1.10
50~1000
20
Remark:
1.Package: rolls or cutting length upon request.
2.Special package,sizes and colors can be supplied
Package:
Size
Tolerance
Min. Wall Thickness
Cutting Length
Package (Meters/Roll)
(mm)
(mm)
(mm)
(mm)
0.5~1.0
0.2
0.30
50~1000
400
1.5~3.0
0.25
0.35
50~1000
200
3.5~5.0
0.25
0.40
50~1000
200
6.0~8.0
0.25
0.45
50~1000
100
9.0~10.0
0.50
0.50
50~1000
100
11.0~14.0
0.50
0.60
50~1000
50
15.0~20.0
1.00
0.65
50~1000
50
22.0~25.0
1.00
0.85
50~1000
25
26.0~30.0
1.00
0.95
50~1000
25
32.0~40.0
1.00
1.10
50~1000
20
Remark:
1.Package: rolls or cutting length upon request.
2.Special package,sizes and colors can be supplied
